3D-measuring of complex cast iron

3D Shape Measurement Systems

The Fraunhofer IOF has got a wide range of tactile, optical and computer tomography based measurement systems for 3D shape measurement of mechanical and optical components and modules.



Machine

Manufacturer

Tactile ultra precise measurement maschine UA3P

Panasonic

Multi-sensor coordinate measurement maschine

Werth Messtechnik

Tactile coordinate measurement system ScanMax

Zeiss

Tactile 3D articulated measuring arm AMPG

Zett-Mess

Optical 3D digitalizer HiScanµ

IVB

Optical multi-sensor system

home made

Handheld optical 3D-scanner »kolibri Cordless«

home made

Optical multi-view 3D-measurement systems

home made

Dual beam CT v|tome|x L 240 / 180

Phoenix X-ray
