LASER World of PHOTONICS 2017

The Fraunhofer IOF at the leading trade fair for photonic technologies. We are looking forward to your visit. June 26–29, 2017 in munich

The Fraunhofer IOF at the LASER World of PHOTONICS 2017

Fair-Highlights 2017



The Fraunhofer IOF will present photonic components and systems "Made in Jena" at the Fraunhofer pavillion (Hall B3 Stand 327). Innovations from the fields of optical systems, micro- and nanostructured components, quantum technology and fiber technology are shown. On the following page you will find an overview of all Fraunhofer IOF exhibits and events.



Entangled Photon Source
Exponat IOF 16



Experts from the Fraunhofer Institute for Applied Optics and Precision Engineering IOF in Jena, developed a new satellite-based source for entangled photons. Twinned or »entangled« photons can be used for secure encryption. A quantum photon source may send a series of photons to one or two receivers through fibers or free space, and after some processing, the series may serve as a key for the encryption of the actual message. This is called quantum key distribution (QKD). QKD technology will be part of a new generation of space-based laser systems that will allow faster and more secure communication among satellites and between satellites and ground stations.



Source of entangled photons

Source of entangled photons

Robotic Light Scattering Sensor

Exponat IOF 2



A compact scatter sensor, developed at Fraunhofer IOF, has now been combined with a collaborative and interactive robot in order to fully exploit its potential. This system and novel software modules enable the sensor to be automatically traced over complex shaped surfaces with diameters of up to 1 m to map the entire surface e.g. for roughness. On the other hand, the collaborative robot with its integrated protective mechanisms, keeps the safety efforts minimal and would even enable a mobile application of the entire system. The collaborative operation also allows positioning of the sensor at selected sample positions by hand. Thereby the sensors position is tracked and the results are registered in a surface map.



Robotic Light Scattering Sensor

Robotic Light Scattering Sensor

Additive manufacture of lightweight mirrors

Exponat IOF 4



Selective Laser Melting can generate complex geometrics slice by slice out of metal powder - for instance aluminium - directly from CAD data. Thereby the powder particles are merged by a high power laser. Compared to chipping technologies, additive manufacturing techniques offer great potential to achieve metal optics with reduced weight as they allow nearly unlimited freedom of design. Material which is not increasing stability is left away. This design allows extremely lightweigt optics with a high stability at the same time. Lightweigt mirrors are applied in laser material processing as well as in optical instruments for space missions.

UP-machining of an additive light weight mirror

UP-machining of an additive light weight mirror

Events and lectures

Vortrag / 26.6.2017

Joining technologies for optical and laser materials


Speaker:
Carolin Rothhardt

Start:
12:00 to 12:20 pm / June 26

Venue:
The Forum in Hall B3

Lecture / 26.6.2017

Schnelle Fokusschiebende Spiegel für die Lasermaterial- bearbeitung

Speaker:
Claudia Reinlein

Start:
13:00 to 13:20 pm / June 26

Venue:
The Forum in Hall B3

Lecture / 26.6.2017

Additive Fertigung von Metalloptiken

Speaker:
Nils Heidler

Start:
14:20 to 14:40 pm / June 26

Venue:
The Forum in Hall B3

27.6.2017

Press tour

Start:
11:00 am to 12:30 pm / June 27

Venue:
Fraunhofer pavillion,
Stand 327, Hall B3

27.6.2017

Green Photonics Award

Start:
13:40 to 14:40 pm / June 27

Venue:
The Forum in Hall B3



Application Panel / 27.6.2017

Pico- & Femtosecond Lasers Status & Prospects

Start:
14:40 to 17:00 pm / June 27

Venue:
The Forum in Hall B3



Lecture / 28.6.2017

Precision joining of optical elements by adhesive bonding

Speaker:
Matthias Mohaupt

Start:
10:05 to 10:30 am / June 28

Venue:
Conference Room B 22 at Messe München



Application Panel / 28.6.2017

CW Diode Pumped Solid State Lasers and Fiber Lasers

Start:
10:00 am to 12:08 pm / June 28

Venue:
The Forum in Hall B3

Exhibit overview

Advanced photonic technologies - optical systems


RGB projector with four freeforms on a single substrate (Exhibit IOF 1)
More Information

Compact optical roughness sensor (Exhibit IOF 2)
More Information

Freeform mirror (fo+) and grating with protected Ag-layer (Exhibit IOF 3)
More Information

Additive light weight mirrors (Exhibit IOF 4)
More Information

Microoptical arrayprojectors (Exhibit IOF 5)
More Information

Multiaperture imaging system for presence detection (Exhibit IOF 6+7)
More Information

Advanced photonic technologies - micro- and nanostructured components



SiO2 Gitter / GRISM und BBO-Saphir-/ TGG-Saphir-Bonds (Exhibit IOF 9)
More Information

3D-CGH (Exhibit IOF 10)

Micro-optics technology - Wide Beam splitter (Exhibit IOF 11)
More Information diffusors

Diffraction gratings for laser applications (Exhibit IOF 12-1)
More Information diffraction grating

Diffraction gratings for spectrometer applications (Exhibit IOF 12-3)
More Information

ALD - coated lenses (Exhibit IOF 12-2)
More Information



3-grid assembly station (Exhibit IOF 13)

Schedule

LASER World of PHOTONICS


Stand number / Hall:

Fraunhofer Community Stand (327) in Hall B3

Opening hours:

Monday 26 June 2017 09:00 – 17:00
Tuesday 27 June 2017 09:00 – 17:00
Wednesday 28 June 2017 09:00 – 17:00
Thursday 29 June 2017 09:00 – 16:00



Venue:
Exhibition Munich

Entrance West
Am Messesee
81829 Munich, Germany
Car Park West
Paul-Henri-Spaak-Str. 6
81829 Munich, Germany
